Sky High Car Audio 5500.1 Amplifier

Sky High Car Audio SHCA5500.1 – All-Purpose Power with Sky High Flexibility



The SHCA5500.1 is the sweet spot in the SHCA lineup—built for daily demo monsters, serious sub stages, or front-stage/mid-bass duty where you want more dynamic range, more headroom, and more control without jumping into giant chassis territory. Korean-built, 0.5 ohm stable, and fully modular, it takes everything people love about the 3500.1 and simply turns it up.



If you’re upgrading from entry or mid-power amps and want real output with real cooling and install flexibility, the 5500.1 is designed to be that next step.









Core Highlights





| Korean Built | Class D | 0.5Ω Stable | Individually QC Tested | Ultra Fast Switching | Balanced Input Circuit | Onboard Synchronizer | Strappable | 3 Levels of Modular Cooling | Premium Customization in Color, Mounting & Appearance | Acrylic Back | Expansion-Ready |



• True 0.5Ω stability, tested and warrantied
• Modular heatsink and mounting ecosystem
• Acrylic back with internal fan
• Built to play hard in daily, demo, or show builds











Power, Ratings & Warranty





• True 0.5 Ohm Stability

• Warrantied and tested to perform under heavy load in real-world conditions
• Operating Voltage

• Rated at 13.2VDC @ 1 ohm
• Up to 17.0VDC max operating voltage
• 1-Year Manufacturer Warranty

• Covers manufacturer defects from date of purchase, including approved 0.5Ω operation
• Korean Engineered & Assembled

• Designed from scratch by experienced engineers
• Built with world-class components and optimized for Sky High’s modular features











Dimensions & Footprint





• Dimensions: 20.47” (L) × 9.92” (W) × 3.13” (H)
• Slightly larger than the SHCA3500.1 but shares the same width, height, and accessory compatibility





That means easier upgrades and clean symmetry when you’re pairing multiple SHCA amps on a wall or rack.









Efficiency & Airflow Built In





• High-efficiency circuit layout reduces heat and electrical stress
• Standard acrylic backplate with internally mounted cooling fan
• Designed for:

• Long play sessions
• Demo events
• High-output daily use
• Built to avoid heat-based drop-off when the volume stays up











Customization That Stands Alone





Flippable Branding System



• Diamond-cut aluminum Sky High logo and model plates
• Fully reversible so branding stays straight in vertical, horizontal, or stacked layouts





Modular Center Panel (Sold Separately)

Drop-in overlays, no adhesives or heavy fab:



• Forged carbon
• Mirror stainless
• Paint-matched aluminum
• Acrylic/plexi light-up options





Just unbolt, swap, and bolt back on to match your theme.









Power Input Flexibility





Input Expansion Kits (Sold Separately)



• Add more 12V power delivery points for high-demand systems
• Available in:

• Cast aluminum
• CNC’d aircraft-grade aluminum
• Copper





Ring Terminal Adapters (Sold Separately)



• Ideal for tight fitments and ultra-clean panel work
• Bolt-on design for secure, high-conductivity connections











Cooling System Expandability





Passive Cooling Add-Ons (Sold Separately)



• Slide-in extruded aluminum heatsink overlays
• Increase surface area by up to 25%
• Available in 5 color options plus raw aluminum for custom finishing
• Note: Non-anodized coatings can affect cooling potential





Active Cooling (Sold Separately)



• Push/pull fan kits mount to the extruded heatsink extensions
• Plug into the (4) onboard 12V outputs
• Optional thermal bridges link airflow between linked amps





2026 Water Cooling Ready



• Future bolt-on water-cooled heatsink system (in development)
• Includes pump, radiator, and lines (optional tank sold separately)











CAT6 Remote System





• Link up to 12 SHCA amps over CAT6
• Control gain, subsonic, LPF, and phase from a single remote unit
• Monitor amplifier temperature and voltage
• Fully compatible with the Sky High Smart Bass Knob











Mounting Options for High-End Builds





As with the rest of the SHCA line, the 5500.1 is designed around modular mounting so it can live wherever your layout needs it:



Bracket Kits (Sold Separately) Allow:



• Stacking
• Vertical mounting (adjustable and static mounts)
• Floating wall installs
• Side-by-side linking





All using the proprietary slide-lock channels built into the heatsink.



Bracket Material Options:



• Extruded aluminum – lightweight, modular
• Cast aluminum – durable and economical
• Machined billet aluminum – show-grade





Optional Footless Endcaps



• For smooth, flush mounting in clean-wall or rail-based installs









SHCA5500.1 – All-Purpose Power with Sky High Flexibility

From demo dailies to pro-level show builds, the SHCA5500.1 gives you clean power, real control, and system-matching flexibility—all in a chassis that fits into more installs than you’d expect from this much amplifier.
